Low-Power Wireless Sensor Networking - Mesh 2.4 GHz
Wireless Mesh OEM RF Modules
XDM2140 2.4 GHz Ultra Low Power Mesh Transceiver Module
XDM2140 Transceiver Modules
Based on DUST Networks’ SmartMesh-XD? technology,
RFM’s XDM2140 module is designed to provide excellent
Product No.
XDM2140C
XDM2140P
Frequency
2.4 GHz
2.4 GHz
Transmit Power
10 mW
10 mW
Channels
15
15
Data Rate
250 Kbps
250 Kbps
communications reliability and long battery life in a wide range of
sensor network applications. The XDM2140’s combination of an
IEEE802.15.4 transceiver and Time Synchronized Mesh Protocol
XDM2140P version for plug in installation, XDM2140C version for solder reflow
Development Kits
(TSMP) blends the reliability of self-organizing and self-healing
mesh networking with synchronized power duty cycling to
achieve very long battery life operation. The XDM2140 is tailored
for use in battery and line powered wireless devices for
applications that require proven performance and scalability. The
multifunctional interface of the XDM2140 gives it the flexibility to
Product No.
XDM2140DK
Description
Development kit for the XDM2140 module including 4 XDM2140 modules, 4
XDM2140 development boards, 1 XG2400E gateway, 1 Ethernet and 5 Serial
cables, 9V batteries and wall-mount power supplies, Antennas and RF cables,
Program CD with software, manuals, and Quick Start Guide
Gateways
be used in a wide variety of applications, from energy
management to building control to machine health monitoring.
Product No.
XG2400E
Frequency
2.4 GHz
Transmit Power
10 mW
Channels
15
Data Rate
250 Kbps
The XDM2140 requires no embedded programming, greatly
reducing the development time and cost of a wireless sensor
network application. The XDM2140 is certified for unlicensed
operation in the USA, Canada and Europe. The XDM2140
complies with Directive 2002/95/EC (RoHS)
Ultra Low Power Consumption
?
?
?
Innovative radio design consumes 80% less power in
receive mode than competing solutions
Ultra-efficient power usage, enabled through SmartMesh
Intelligent Network management, delivers over a decade of
network operation on two AA batteries
Automatic network-wide coordination for efficient power
usage
Ultra Reliable Networking
?
?
?
?
?
SmartMesh-XD? protocol delivers greater than 99.9%
typical network reliability
Frequency hopping provides interference rejection and
minimizes multipath fading
Mesh networking provides built-in redundancy
Every XDM2140 acts as both and endpoint and a router,
increasing network reliability with mesh-to-the edge?
Automatic self-organizing mesh networking capability built in
Easy Integration
?
?
?
?
?
XDM2140 provides all the module functionality with no
embedded programming or complex configuration
requirements
XDM2140 interfaces is well designed and multi-functional
High-level Data Link Control (HDLC) serial interface
includes bi-directional flow control
Industrial temperature range -40 to +85 °C
XDM2140P version for plug in installation, XDM2140C
version for solder reflow
28
